Use
· To close the cavity at external doors, window jambs and sills
· To provide thermal insulation and prevent ‘cold bridging’
· To provide a DPC at external doors, window jambs or sills
· 30 minutes fire rating and minimum 15 minutes insulation
· Suitable for cavities up to 300mm
· Suitable for timber and masonry walls
Features and benefits
· Provides an effective DPC and thermal barrier between frame, inner and outer wall leaf
· Thermal conductivity of 0.036W/mK
· Exceeds the minimum thermal resistance path of 0.45m2K/W stipulated in ‘Part L’ accredited construction details
· Rigid profile extrusion allows both first and second fix
· Suitable for all frame and sill positions
· Durable and resistant to decay
· Insulation option to suit your requirements both thermal and fire rated
· Global warming potential of zero
· Ozone depletion potential of zero
· Available fully rebated - Check reveal (single flange)
Quality
• Independently tested by Warrington Fire
• LABC Registered Detail
• Satisfies NHBC Standards
• Manufactured to BS EN ISO 9001 and BS EN ISO 14001
• Complies with Building Regulation Approved Documents C, B, L1 & L2
• Complies with ‘Part L’ accredited construction details
• Complies with the Scottish Building Standards ‘Technical handbook’
• Satisfies BRE document ‘Thermal insulation: avoiding risks’
• Meets all relevant British Standards
Product code | Description | Price | Per | Stock | Order |
---|---|---|---|---|---|
K810-510 | 50mm 1/2hr Fire Rated Cavity Closer - 2.4m |
£13.46 +VAT
£16.15 inc. VAT |
1 | 6 | |
K810-525 | 65mm 1/2hr Fire Rated Cavity Closer - 2.4m |
£14.07 +VAT
£16.88 inc. VAT |
1 | 4 | |
K810-540 | 75mm 1/2hr Fire Rated Cavity Closer - 2.4m |
£20.51 +VAT
£24.61 inc. VAT |
1 | 9 | |
K810-555 | 100mm 1/2hr Fire Rated Cavity Closer- 2.4m |
£24.62 +VAT
£29.54 inc. VAT |
1 | 4 | |
K810-560 | 125mm 1/2hr Fire Rated Cavity Closer- 2.4m |
£30.77 +VAT
£36.92 inc. VAT |
1 | 2-3 days |
|
K810-565 | 150mm 1/2hr Fire Rated Cavity Closer- 2.4m |
£40.78 +VAT
£48.94 inc. VAT |
1 | 2-3 days |
